65"-86" Large Size MAXHUB Touch Screen Panel with Nano Silver and 20-Point Touch for Medical and Industrial Applications

Brand Name:	Lunfeng
Model Number:	CTP231053
MOQ:	1 piece
Payment Terms:	T/T,Western Union
Supply Ability:	500000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

ISO9001:2015

Size:

55"-100", Customized Size

Touch Solution:

Glass-Glass(G+G), Glass-Film(G+F), Glass-Film-Film (G+F+F), Glass-Flim2(G+F2)

Material:

FILM/GLASS

Touch Points:

20-point Touch

Minimum Recognition Point:

4mm*4mm

Supporting Resolution:

32768×32768

Touch Response Time:

10-15ms (Multi Touch), 7ms (One Touch)

Interface Type:

1.5 M USB Cable Receptacle, The Receptacle 5P

Frame Material:

Aluminium Alloy

Glass Material:

Toughened Glass

Packaging Details:

First put into a polybag, then paked into a carton. According to clients' special requirements.

Supply Ability:

500000 Piece/Pieces per Month

Highlight:

G2F large capacitive touch screen

MAXHUB large capacitive touch screen

Nano Silver large touch screen panel

Product Description

G2F MAXHUB Large Capacitive Touch Screen Panel Nano Silver

Large Size 65" to 86" MAXHUB Capacitive Touch Screen Panel designed for professional applications requiring high-performance touch interaction.

Touch Solutions

Available in multiple configurations: Glass-Glass (G+G), Glass-Film (G+F), Glass-Film-Film (G+F+F), and Glass-Film2 (G+F2)

Technical Specifications

Specification	Details
Touch Screen Size	86"
Touch Points	20-point touch
Minimum Recognition Point Size	4mm × 4mm
Supporting Resolution	32768 × 32768
Touch Response Time (Multi touch)	10-15ms
Touch Response Time (One touch)	7ms
Input Method	Any opaque touches (fingers, brushes, etc.)
Calibration	4-point calibration
Interface Type	1.5m USB cable receptacle (5P)
Frame Material	Aluminium alloy
Glass Material	Toughened glass
Scanning Frequency	>110Hz
Communication Interface	USB 2.0
Power Supply	USB 5.0V
Working Voltage and Current	4.75~5.25V, ≤200mA
Humidity	Up to 90% RH from 0°C to +40°C, non-condensing
Temperature Range	Working: -10℃ to 50℃, Storage: -20℃ to 60℃
LED Lifetime	60,000 hours
Fault-tolerant	Able to work if less than 10% non-consecutive sensors are damaged
ESD	EN 6100-4-2 2008:3 level. 4KV contact discharge and 8KV air discharge

Operating System Support

Multi-touch: Windows 10, Windows 8, Windows 7, Android
Single-touch: Windows XP, MacOS, Linux

Application Scenes

Education
Medical Industry
Finance
Exhibition
Industrial Control
Man-machine Interaction
TV
PC
And more applications

Factory Direct Benefits: Exclusive custom solutions, stable supply of goods, and comprehensive quality assurance from the source manufacturer.
