0.2mm-6mm Polyimide FPC Flexible Circuit Board for Medical Equipment and Flex PCB Assembly

Brand Name:	Lunfeng
Model Number:	FPC002
MOQ:	1 piece
Payment Terms:	T/T,Western Union
Supply Ability:	500000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

ISO9001:2015

Material:

Polyimild, PI

Min. Line Width:

0.075mm/ 0.075mm (3mil / 3mil)

Min. Line Spacing:

0.003''

Board Thickness:

0.2-6mm

Surface Finishing:

HASL/ OSP/ Ag/ ENIG/ ENEPIG/ Immersion Silver/Tin

Copper Thickness:

0.4-2mil(10-50um)

Layer:

1-6layer

FPC Size(max/min):

Min: 10x45mm Max:250x1200mm

Through Hole Diameter(Max):

6.5mm

Through Hole Size(min):

0.2mm

Packaging Details:

First put into a polybag, then paked into a carton. According to clients' special requirements.

Supply Ability:

500000 Piece/Pieces per Month

Highlight:

6mm FPC Flexible Circuit Board

0.2mm FPC Flexible Circuit Board

PCB flex circuit board

Product Description

0.2mm-6mm FPC Flexible Circuit Board PCB Cable Assembly

FPC Flexible Circuit Board Overview

Flexible Printed Circuits (FPC) are designed for both static applications with minimal flexing and dynamic applications requiring regular flexing. These circuit boards are essential in applications demanding high precision and reliability.

Applications

Robotics and automation systems
Printers and office equipment
Mobile devices and cell phones
High-precision cameras
Satellite and aerospace systems
Automotive systems (fuel pumps, antilock brakes, airbag systems)
Avionics and aircraft systems
Motion control systems
Medical devices and equipment
Industrial manufacturing devices

Technical Specifications

Parameter	Specification
Layers	1-6 layers
FPC Size (Max/Min)	Min: 10x45mm, Max: 250x1200mm
Thickness	0.050mm - 0.2mm
Through Hole Diameter (Max)	6.5mm
Through Hole Size (Min)	0.2mm
Through Hole Tolerance	±0.025mm
Hole Copper Thickness	Min 8μm, Max 38μm
Min Line Width/Space	0.04/0.04 mm
Etching Tolerance	±20%
Pattern Accuracy on Hole	±2mil
Punching Size (Max)	φ3.175mm
Punching Size (Min)	φ2.0mm
Punching Aperture Thickness (Max)	0.2mm
Thermosetting Inks Tolerance	±0.2mm
Green Oil (Min)	0.1mm
Solder Pad (Min)	8mil*8mil
Solder Pad Distance (Min)	8mil
Tolerance (Min)	±0.1mm
Available Laminates Material	Pl, PET, FR4-Pl
Copper Foil Thickness	12um, 18um, 35um, 70um
