Yellow PI Film Solder Mask Flexible Printed Circuit Board with 1OZ Copper Thickness for High Temperature Applications

Brand Name:	Lunfeng
Model Number:	FPC010
MOQ:	1 piece
Payment Terms:	T/T,Western Union
Supply Ability:	500000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

ISO9001:2015

Material:

Polyimild, PI

Board Thickness:

0.2-6mm

Surface Finishing:

HASL/ OSP/ Ag/ ENIG/ ENEPIG/ Immersion Silver/Tin

Solder Mask:

Yellow PI Film

Copper Thickness:

1/2OZ 1OZ 2OZ 3OZ,1oz / 1/2 Oz/ 1/3 Oz

Copper Thickness:

0.4-2mil(10-50um)

Outline Profile:

Punching / Laser Cut / Drilled

Layer:

1-6layer

FPC Size:

Min: 10x45mm Max:250x1200mm

Thickness:

0.050mm--0.2mm

Packaging Details:

First put into a polybag, then paked into a carton. According to clients' special requirements.

Supply Ability:

500000 Piece/Pieces per Month

Highlight:

PI rigid flexible printed circuit board

1OZ rigid flexible printed circuit board

Yellow PI Film rigid flex board

Product Description

Yellow PI Film Rigid Flexible Printed Circuit Board 1OZ Copper Thickness

Product Overview

Flexible FPC Flexible Circuit Board PI flexible PCB with rear adhesive

Benefits of Flexible Printed Circuits

Long-term Performance

The superior qualities of flexible circuit boards allow them to have durability and long-term performance. The characteristics of low ductility and mass contained in these boards allow them to overcome the influence of vibrations, therefore giving them the capacity to have improved performance. The ability of electronics to remain durable for a long time is a massive advantage for users. As you well know, electronics are common in households today, thus their ability to stay in good shape for a long time is an added value.

Cost Reduction

The capacity of any device or material to reduce PCB cost compared to another gives it an added advantage. Given that flexible printed circuits have the ability to fit into a small space, they significantly reduce the cost of flexible printed circuit assembly. In the same vein, they reduce reworking time, testing time, and rejects, which translates to cost saving.

High Temperature Viability

The polyimide material in these circuit boards has the capacity to withstand high temperatures and also be resistant to materials like acids and oils. Flexible circuit boards can withstand temperatures as high as 400 degrees centigrade, which makes them a reliable option for high temperature applications.

FPC Cable Specifications

Parameter	Specification
Layer	1-6 layer
FPC size (max/min)	Min: 10x45mm Max: 250x1200mm
Thickness	0.050mm - 0.2mm
Through Hole diameter (Max)	6.5mm
Through hole size (min)	0.2mm
Through hole tolerance	±0.025mm
Hole copper thickness	Min 8μm Max 38μm
Min line width/space	0.04/0.04 mm
Etching Tolerance	±20%
The accuracy of the pattern on the hole	±2mil
Punching size (max)	φ3.175mm
Punching size (min)	φ2.0mm
Punching aperture Thickness (Max)	0.2mm
Thermosetting inks tolerance	±0.2mm
Green oil (Min)	0.1mm
Solder pad (min)	8mil*8mil
Solder pad distance (Min)	8mil
Tolerance (Min)	±0.1mm
Available Laminates Material	Pl. PET. FR4-Pl
Copper foil thickness	12um, 18um, 35um, 70um
