| Name: | FPC Flexible Circuit Board Flexible Printed Circuit | Application: | Medical Equipment, Electronic Equipment |
|---|---|---|---|
| Material:: | Polyimild, PI | Copper Thickness:: | 0.4-2mil(10-50um), |
| Board Thickness:: | 0.2-6mm | Size: | Customized Size |
| Surface Finishing:: | HASL/ OSP/ Ag/ ENIG/ ENEPIG/ Immersion Silver/Tin | Item: | OEM |
| Outline Profile: | Punching/Laser Cut/Drilled | Product Name: | Shenzhen QuikPCB Led Pcb Board |
| Min. Line Width: | 0.1mm | ||
| High Light: | 0.2-6mm flex board pcb,Electronic equipment flex board pcb,Punching flat flex pcb |
||
Flexible Circuit Boards Classification Based on Layers
Single-Sided Flexible Circuit Boards
This is among the basic types of flexible circuit boards based on layers. It contains a single layer of polyimide film. It also has a slim layer of copper.
Single-Sided Flexible Circuit Boards with Dual Access
Just like the name suggests, these circuit boards are single-sided but have the copper sheet accessible from both sides.
Double-Sided Flexible Circuit Boards
These particular circuit boards contain a double layer of conductors on either side of the polyimide layer.
Multi-Layered Flexible Circuits
This circuit contains a combination of double-sided and one-sided flexible circuits.
Based on the afore-mentioned types of flexible circuit boards, it is evident that designers and engineers have a wider spectrum of selection for different applications. It is this flexibility that makes flexible circuit boards highly beneficial.
|
FPC cable ( Flexible Printed Circuit ) Specifications
|
|
| Layer | 1-6layer |
| FPC size(max/min) | Min: 10x45mm Max:250x1200mm |
| Thickness | 0.050mm—0.2mm |
| Through Hole diameter(Max) | 6.5mm |
| Through hole size(min) | 0.2mm |
| Through hole tolerance | ±0.025mm |
| Hole copper thickness | Min8μm Max 38μm |
| Min line width/space | 0.04/0.04 mm |
| Etching Tolerance | ±20% |
| The accuracy of the pattern on the hole | ±2mil |
| Punching size(max) | φ3.175mm |
| Punching size(min) | φ2.0mm |
| Punching aperture Thickness(Max) | 0.2mm |
| Thermosetting inks tolerance | ±0.2mm |
| Green oil(Min) | 0.1mm |
| Solder pad(min) | 8mil*8mil |
| Solder pad distance(Min) | 8mil |
| tolerance(Min) | ±0.1mm |
| Available Laminates Material | Pl. PET. FR4-Pl |
| Copper foil thickness |
12um, 18um, 35um, 70um
|
