Polyimide PI Material FPC Flexible Circuit Board with 10-50um Copper Thickness and Customized Size for Electronic Equipment

Brand Name:	Lunfeng
Model Number:	FPC009
MOQ:	1 piece
Payment Terms:	T/T,Western Union
Supply Ability:	500000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

ISO9001:2015

Material:

Polyimild, PI

Surface Finishing:

HASL/ OSP/ Ag/ ENIG/ ENEPIG/ Immersion Silver/Tin

Board Thickness:

0.2-6mm

Copper Thickness:

0.4-2mil(10-50um)

Layer:

1-6layer

FPC Size:

Min: 10x45mm Max:250x1200mm

Thickness:

0.050mm--0.2mm

Through Hole Diameter:

Max: 6.5mm, Min: 0.2mm

Hole Copper Thickness:

Min8μm Max 38μm

Min Line Width/space:

0.04/0.04 Mm

Packaging Details:

First put into a polybag, then paked into a carton. According to clients' special requirements.

Supply Ability:

500000 Piece/Pieces per Month

Highlight:

10-50um FPC Flexible Circuit Board

polyimide PI FPC Flexible Circuit Board

connector flexible printed circuit board

Product Description

Polyimide PI FPC Flexible Circuit Board Connector 10-50um Copper Thickness

FPC Flexible Circuit Board with Polyimide PI Material

Our FPC flexible circuit boards utilize polyimide PI material with integrated connectors for reliable performance in demanding applications.

Benefits of Flexible Printed Circuits

Design Freedom

Flexible printed circuits offer exceptional design freedom, extending beyond double-layer configurations. This advantage enables engineers to create complex configurations with diverse interconnections and accommodate various components, fostering creativity and design diversity.

High Density Configurations

The ability to combine plated through-hole and surface mounted components allows for high-density device designs. Narrow component separation enables lighter conductors, creating space for additional components while maintaining compact form factors.

FPC Cable Specifications

Parameter	Specification
Layer	1-6 layer
FPC Size (Max/Min)	Min: 10×45mm, Max: 250×1200mm
Thickness	0.050mm–0.2mm
Through Hole Diameter (Max)	6.5mm
Through Hole Size (Min)	0.2mm
Through Hole Tolerance	±0.025mm
Hole Copper Thickness	Min 8μm, Max 38μm
Min Line Width/Space	0.04/0.04 mm
Etching Tolerance	±20%
Pattern Accuracy on Hole	±2mil
Punching Size (Max)	φ3.175mm
Punching Size (Min)	φ2.0mm
Punching Aperture Thickness (Max)	0.2mm
Thermosetting Inks Tolerance	±0.2mm
Green Oil (Min)	0.1mm
Solder Pad (Min)	8mil×8mil
Solder Pad Distance (Min)	8mil
Tolerance (Min)	±0.1mm
Available Laminates Material	PI, PET, FR4-PI
Copper Foil Thickness	12um, 18um, 35um, 70um
