| Product Name: | LED Membrane Switch Non-tactile Membrane Switch Keypad | Colors: | Pantone/ RAL Color, Blue, Gray, White |
|---|---|---|---|
| Feature: | 29 Pcs LEDs | Key Option: | Non-tactile Key Button |
| Application: | Medical/ Industrial/ Household Equipment, Etc | Rear Adhesive: | 3M467 3M 468 |
| Surface Finish: | Matte | Cable: | Custom Cable Length, Flexible |
| Connector: | 2.54mm Female Connector | Printing: | Screen Printing |
| Certification: | ISO9001 ROHS CI FDA SGS | Keywords: | Membrane Keypad |
| High Light: | 3M467 LED Membrane Keypad,non tactile LED Membrane Keypad,Matte membrane switch keypad |
||
LED Membrane Switch non-tactile membrane switch keypad
1. What is membrane keypad?
It is an operating system, which integrates key function, indicator element, and instrument panel. Also, it’s called touch keyboard, because the keypad will generate a tactile response in use. It adopts an integral sealing construction combined with flat and multi-layers. As we all know, the structure seals tactile membrane switch, graphic overlay, mark, symbol display, and lining board together. This membrane switch keyboard is a new type of electronic component, integration of light, machine, and electricity. Furthermore, the appearance of this type of keyboard marks a fundamental change in the appearance and structure of printed electronic products. This type of switch can replace key buttons of the regular discrete component part to perform the tasks of the operating system more reliably.
Video of the Whole Complete Membrane Keypad Production Process
2. Membrane keypad structure
So which parts does the membrane switches keyboard consist of? They are not the same as mechanical switches. In general, membrane switch keypads have six parts. Including graphic overlay, graphic adhesive, upper circuit layer, adhesive separator, lower circuit layer, and adhesive bottom layer.
3. Membrane keypad types
Flexible membrane switch, rigid membrane switch, and raised membrane switch.
Our Advantage:
We Focus in membrane switch and related items.
Strong R&D capability
Stable in quality
Competitive price
Short Lead time for samples and Mass production
Whole solution design available
Applications:
* home appliances and device
* Security Protection systems with Cipher Code
* Various industry control keypad panel
* consumer electronics and 3C item
* Thrapy medical system and device
* Various automtic machine control keypad
* Telecommunication Equipment
* Medical Equipment
* Industrial Equipment
* Household Equipment
* Remote Controller
* Control system
| Items | Silver Printed Circuit | Copper Etched FPC Circuit |
| Material | PET (Polyester) | Copper |
| Conductor | Printed silver | Copper |
| Contact Fingers | Silver and Carbon | Gold plated |
| Contact Buttons Pads | Silver | Gold plated |
| Life & Reliability | normal | good |
| Stability | normal | good |
| Resistance | low | Very low |
| Cost | low | high |
| Lead Time | 2-3 days | 7-10 days |
| Pitch | 0.5mm (not suggested), 1.0mm, 1.27mm, 2.54mm | 0.5mm, 1.0mm, 1.27mm, 2.54mm |
|
