Product name:
2.1"4.3" 5" 7" 9" 10.1" 12.2" 15" inch 4 wire 5 wire resistive touch panel
Specification
> Touch solution: Resistive Touch Screen : 4-wire / 5-wire / 8-wire
Glass-Glass(G+G),
Glass-Film(G+F),
Glass-Film-Film (G+F+F),
Glass-Flim2(G+F2)
> Touch size: Small size, mainly 2.1"4.3" 5" 5.6" 5.7" 6.5" 7" 9" 10.1" 12.2" 15" 15.6" 16"
> Certification: ISO9001:2015 /ROHS/SG
> Payment terms: T/T, West Union
> Shipping by: UPS/ Fedex /DHL /TNT or Other Ways Specified
> Delivery time: 7~25 Working Days
-
- Package Type:
-
1) Wrap in air bubble film
2) Put into foam box
3) Packed with extra carton box, which make sure the goods safety in transportation.
4) We can accept customized package.
- Lead Time:
-
| Quantity(Pieces) |
1 - 100 |
101 - 500 |
>500 |
| Est. Time(days) |
10 |
18 |
To be negotiated |
-
-
| Resistive Touch Screen Panel |
| Touch Media: |
Finger, Touch Pen |
Surface Hardness: |
3H or more |
| Circuiting Rating: |
5V DC,35mA |
Hitting Life Expectancy: |
Over 1 million |
| Light Transmission |
Film+Film>77%,Film+Glass>83% |
Scoring Life Expectancy: |
Over 100,000 |
| Contact Bounce: |
<10ms |
Operating Temperature: |
-20℃~+70℃ |
| Resolution: |
4096*4096 |
Storage Temperature: |
-30℃~+80℃ |
| Linearity: |
1.5%(<1.0% By Request) |
Choices of Glass Thickness: |
0.55mm,0.7mm,1.1mm,2.0mm,3.0mm |
| Operating Force: |
10g-100g |
Choices of Glass: |
Normal Glass,Chemically strengthened glass |
| |
| Projected Capacitive Touch Screen Panel |
| Interface: |
IIC,USB |
Input Mode: |
Finger or stylus pen |
| Circuit Level: |
3.3~5V DC,35mA |
Life Expectancy: |
Over 225 millions |
| Transmission: |
>89% |
Operating Temperature: |
-10℃~+60℃ |
| Contact Bounce: |
<2ms |
Storage Temperature: |
-20℃~+70℃ |
| Resolution: |
1024*1024 |
Lens material: |
Chemically strengthened glass |
| Surface Hardness: |
6H |
Glass thickness: |
0.55mm,0.7mm,1.0mm |
Delivery
To create and submit counter-drawings + artwork for your approval:2-3 working days
To build tooling and Sample Shipping:8-10 days
Mass Production Delivery:15-30 days after the sample confirmation
-
-
About US:
Shenzhen Lunfeng Technology Co., Ltd. (“Lunfeng”) was estimated in 1995, mainly engaged in production, sale and service of all kinds of membrane switches, membrane overlay, PC, PVC, PET and aluminum plates, acrylic lenses, metal nameplate, touch screens, crystal epoxy, label papers and hot press/injection molding thermosetting composite materials ( BMC / SMC).
In strict compliance with ISO9001:2015 standard in production, we established a complete quality management system, ensuring strictness and close linking from raw material procurement to delivery. We introduced advanced computer testing equipment to ensure stable and reliable product quality which makes us taking the lead in the trade of Shenzhen.
Our company has over 200 employees for management, sale, engineering and production and a plant area of over 3,000 square meters. Our products sell well in America, Canada, the United Kingdom, France, Germany, Italy, Australia, Japan, Singapore, etc. Haiwen people know that only by high-quality products and perfect service can we win customer's trust and remain invincible in the competitive market.
We always adhere to the service tenet of "Quality Assurance, Timely Delivery, Reasonable Price, Considerate Service". We believe that with the efforts and hard work of our staff, we are bound to create a more brilliant future. We sincerely hope to cooperate with all customers for a bright future!
