| Name: | FPC Flexible Circuit Board Flex Circuit Board | Application: | Medical Equipment, Electronic Equipment |
|---|---|---|---|
| Material:: | Polyimild, PI | Copper Thickness:: | 0.4-2mil(10-50um), |
| Board Thickness:: | 0.2-6mm | Min. Line Width:: | 0.075mm/ 0.075mm (3mil / 3mil ) |
| Size: | Customized Size | Min. Line Spacing:: | 0.003'' |
| Surface Finishing:: | HASL/ OSP/ Ag/ ENIG/ ENEPIG/ Immersion Silver/Tin | Product Name: | Flex PCB Assembly |
| Item: | OEM/ODM | Color: | Yellow,Black |
| High Light: | 6mm FPC Flexible Circuit Board,0.2mm FPC Flexible Circuit Board,PCB flex circuit board |
||
Applications of Flexible Printed Circuits
Flexible Circuit overlay
Flexible printed circuits can be used for various applications. For example, they can be used for static applications and dynamic flexing. For the case of static applications, the design of the circuit board is for minimal flexing. It is during the installation that the circuit is flexed. For dynamic flexing, the circuit boards are for regular flexing. Here are a number of the applications of these circuit boards: robots, printers, and cell phones. It is also essential to point out that flexible circuit boards are largely used in applications that require high precision and regular flexing. Examples of these applications include: cameras, satellites, fuel pumps, antilock brakes, avionics, motion systems, medical devices, airbag systems, and manufacturing devices.
|
FPC cable ( Flexible Printed Circuit ) Specifications
|
|
| Layer | 1-6layer |
| FPC size(max/min) | Min: 10x45mm Max:250x1200mm |
| Thickness | 0.050mm—0.2mm |
| Through Hole diameter(Max) | 6.5mm |
| Through hole size(min) | 0.2mm |
| Through hole tolerance | ±0.025mm |
| Hole copper thickness | Min8μm Max 38μm |
| Min line width/space | 0.04/0.04 mm |
| Etching Tolerance | ±20% |
| The accuracy of the pattern on the hole | ±2mil |
| Punching size(max) | φ3.175mm |
| Punching size(min) | φ2.0mm |
| Punching aperture Thickness(Max) | 0.2mm |
| Thermosetting inks tolerance | ±0.2mm |
| Green oil(Min) | 0.1mm |
| Solder pad(min) | 8mil*8mil |
| Solder pad distance(Min) | 8mil |
| tolerance(Min) | ±0.1mm |
| Available Laminates Material | Pl. PET. FR4-Pl |
| Copper foil thickness |
